Bordo 20 x 2.5mm Blue Band Spiral Flute Tap 3250-20.00
More infoFeatures:
- 20 x 2.5mm HSSE-V3 TiAlN Coated Blue Band Spiral Flute Tap
- HSSE-V3 HSSE with 3% Vanadium high performance tap.
- TiAlN (Titanium Aluminium Nitride) coating provides higher temperature resistance and improved surface hardness.
- Optimised for machining stainless steel
- Spiral flute with 40º helix angle.
- Designed for tapping blind holes where the right hand spiral forces swarf out of the hole and prevents clogging which may cause breakage or spoiled threads.
- Designed to withstand the high stress and high heat associated with CNC production tapping.
- The machining of stainless steels is difficult due to its work hardening properties, toughness and poor thermal conductivity, which places high demands on the cutting tools.
- TiAlN coating increases tool surface hardness to 87Rc.
- For machining materials with Hardness < 350 HB : Tensile Strength <1250 N/mm2.
Specifications: | |
|---|---|
| Diameter (mm) | 20 |
| Overall Length (mm) | 140 |
| Pitch (mm) | 2.5 |
| Thread Form | Metric Coarse |
(3250-20.00)
| SKU | 3250-20.00 |
| Barcode # | 9326518093893 |
| Brand | Bordo |
| Shipping Weight | 0.0600kg |
| Shipping Width | 0.026m |
| Shipping Height | 0.150m |
| Shipping Length | 0.026m |
| Type | tools |
