xTool P2 Automatic Conveyor Feeder Basic (39'')

Automatic Conveyor Feeder for xTool P2

The maximum processing area is supersized up to 118''×19.6'', giving you the option to engrave anything up to 118 inches long in size effortlessly, and set more quantity at one time.

A utomatic engraving path planning and material conveying; Farewell to manual material feeding and accuracy deviation.

The material range is expanded from plywood, acrylic and fiberboard to soft materials like felt, cork and EVA.

The upper and lower pressure wheels use anti-slip materials, and materials of various sizes can be easily fixed to prevent them from slipping or shifting during the conveying process.

With buckle design, the conveyor rail can be installed easily.

Different pressures need to be set for processing different materials. With color markings quickly matching each material pressure level, the pressure can be easily adjusted according to the material type.

Users can easily adjust the position of materials with the lower knob.

Align the material with the grids on the conveyor feeder and convey the material to the device, so that the material is parallel to the conveying direction.

Specification
Applicable to: xTool P2
Package Size: 30.2''×10.1''×9.1'' (769×255×230mm）
Product Size: 27.1''×7.8''×5.3'' (687×200×135mm)
Product Weight: 8.045kg
Max. speed: 160mm/s


Work Area
Maximum Processing Area: 118''×19.6'' (3000mm×500mm)
Maximum Material Width: 24.5'' (624mm)
Minimum Material Width: 2.5'' (65mm)
Maximum Material Thickness: 0.55'' (14mm)
