Please note: this product does not include a wall plug.

Features:
  • Latest IGBT inverter technology
  • MIG/MAG with Gas and Gasless wire function
  • Spool Gun connection
  • MMA
  • DC TIG welding with Lift Arc start
  • VRD (Voltage Reduction Device)
  • Wire Inch & Burn Back control
  • Industrial application
  • Internal wire feeder, gear driven
  • 5 Kg to 15 Kg Spools
  • Euro style MIG torch connection
  • IP21S rating for environmental/safety protection
  • Stepless voltage and wire feed control
  • Excellent MIG welding with CO2 gas & mixed gas
  • Excellent arc stability for MIG / TIG / MMA welding
Specifications:
Power Supply / Phases (V-Ph)240v - 1 +/- 15%
Duty Cycle @ 40°c as per AS/NZ60974-1MIG - 35% @ 250 Amps
MMA - 35% @ 250 Amps
Output Current RangeMIG - 30A/15.5V - 250A/26.5V
MMA - 10A/20.4V - 250A/30.0V
Rated PowerMIG - 10.4 KVA
MMA - 11.8 KVA
I ieffMIG - 25.4 Amps
MMA 29.0 Amps
Power factor0.75
Protection ClassIP21S
Insulation ClassF
Wire FeederGear Driven 4 Roll
Dimensions Power Source (LxWxH)900 x 400 x 670 mm
Weight power Source58 kg

Includes:
KUMJR250K Machine, SB24 4M Sure Grip MIG Torch, Earth Lead & Arc Lead 25mm x 4m, UNI-FLAME Twin Gauge Argon Regulator, 2M Gas Hose
SKU KUMJR250K-SG
Barcode # 9339793005819
Brand Unimig
Shipping Weight 60.0000kg
Shipping Width 0.090m
Shipping Height 0.057m
Shipping Length 0.100m
Shipping Cubic 0.513000000m3
Assembled Length 0.900m
Assembled Height 0.670m
Assembled Width 0.400m
Type tools
Warranty 3 Year
