HiKOKI 18V Brushless Impact (Hammer) Driver Drill DV18DC(H4Z)
This product is an 18V cordless impact driver drill that is maximum torque of 140Nm with 13mm chuck.
Equipped with a 22-stage clutch and drill mode, it can be used wood drill, steel drill, steel cores drill, masonry drill and tightening screws of various sizes.
In addition, the drastically downsized, RFC-equipped, and improved side handle improve workability.
- Increased performance to a maximum torque of 140Nm makes heavy-load work much easier
- Due to the highly durable design that is resistant to heat generation, it is difficult to stop even during continuous work
- Reduce twisting of the driver drill with RFC (Reactive Force Control)
- The side handle can be mounted in 11 different positions to improve workability
|Drill chuck type||Keyless metal chuck|
|Chuck capacity||1.5 - 13 mm|
|Clutch stages||22 (Torque 1.5 - 8.0 Nm)|
|Maximum Torque Hard Joint||140 Nm|
|Maximum Torque Soft Joint||70 Nm|
|No load speed - low||0 - 500 rpm|
|No load speed - high||0 - 2000 rpm|
|No load impact rate||0 - 30,000 ipm|
|Capacity: Brick & Masonry||22 mm|
|Capacity: Steel & Aluminium||16 mm|
|Capacity: Wood - hole saw||102 mm|
|Capacity: Wood - self feed bit||80 mm|
|Capacity: Small Machine Screw||M6|
|Capacity: Wood Screw||M12 x 100 mm|
|Dimensions (L x W x H)||190 x 267 x 89 mm|
|Weight (with Battery)||2.8 kg|
HiKOKI 18V Brushless Impact Driver WH18DC(H4Z)
- Compact and easy to use with a 114mm long in head length
- Highly visible 3-LED lights to improve visibility of the work in a dark workplace
- Triple hammer anvil reduces vibration and “cam-out”
- 5 tightening modes: Soft mode for small screws, Power mode for wood screws, Bolt mode for bolts, Bolt mode (single)
for small bolts & Self drilling mode for self drilling screws
- Conforming to IP56 (dust and water resistant)
- Compatible with the HiKOKI MultiVolt and 18V slide batteries
|Switch type||Variable speed trigger switch|
|Capacity - Small screw||4 - 10 mm|
|Capacity - Ordinary screw||5 - 18 mm|
|Capacity - High-tension bolt||5 - 14 mm|
|Capacity - Self drilling screw||3.5 - 6 mm|
|Maximum Tightening torque||210 Nm|
|No-load rotation speed - Soft||0 - 900 rpm|
|No-load rotation speed - Power||0 - 3,400 rpm|
|No-load rotation speed - Bolt||0 - 2,900 rpm|
|No-load rotation speed - Self-drilling screw||0 - 3,700 rpm|
|Impact rate - Soft||0 - 1,900 ipm|
|Impact rate - Power||0 - 4,000 ipm|
|Impact rate - Bolt||0 - 4,000 ipm|
|Impact rate - Self drilling screw||0 - 2,100 ipm|
|No-load sound pressure level||74.8 dB|
|Dimensions (L x H)||114 x 241 mm|
HiKOKI 36V MultiVolt Battery A Slide Li-Ion (371750) BSL36A18
- 1,080W High Power Output
- The MULTI VOLT Lithium-ion battery, paired with MULTI VOLT 36V tools, offers unprecedented cordless power over 1,000 W with its size and weight.
- The MULTI VOLT battery is designed for full compatibility with the current 18V slide range, and automatically changes between 2 voltages, 36V 2.5Ah and 18V 5.0Ah, according to the tool used.
- *Compatible with MULTI VOLT 36V tools only.
- Remaining Battery Indicator - Displays the charging state in four stages.
- Compact & Lightweight - The MULTI VOLT battery has almost the same size and weight of a 18V battery, and produces the power of a 36V.
- Not compatible with the existing 36V products that are compatible with BSL3620, BSL3625, BSL3626 or BSL3660.
|Voltage & Capacity||36V 2.5Ah and 18V 5.0Ah|
|Dimensions||116 x 69 x 76 mm|
|Charging Time||Approx. 32 mins (with UC18YSL3)|
|Compatible Products||All existing 18V slide-type tools
MULTI VOLT 36V tools
|Compatible Chargers||All chargers compatible with slide-type Lithium-ion batteries|
HiKOKI 14.4 - 18V Li-Ion Rapid Cooling Charger with USB Port UC18YSL3(H0Z)
- Cooling feature helps cool battery during charging or before charging commences to prevent battery overheating ensuring extended battery life
- Preventative mechanism against charging a hot battery to extend battery life
- 3 way overcharge protection system to ensure battery is not overcharged
- Two colour indicator light to indicate what stage of charging the battery is in
|Capable of charging||14.4V and 18V slide style Li-ion batteries|
