Features:
  • Automatic down feed
  • Quality precision machine for drilling, milling & tapping
  • No. 4 Morse taper spindle
  • 1120W motor, three phase
  • Micro feed precision
  • Geared head tilts 90° right & left
  • Forward and reverse operation
  • Recirculating coolant system
  • Accessories include arbor, draw bar, milling chuck, 16mm drill chuck, drill sleeves
Specifications:
Max Drilling Capacity40 mm
Spindle TaperMT4
Spindle Nose To Base1180 mm
Spindle Nose To Table610 mm
Spindle To Column272.5 mm
Diameter Of Column115 mm
Quill Travel120 mm
Swing660 mm
Spindle Speeds75, 170, 280, 540, 960, 1600 rpm
Table Surface600 x 190 mm
Cross Travel190 mm
Longitude Travel370 mm
Overall Height1770 mm
Base Dimensions650 x 450 mm
Weight390 kg

Includes:
Arbor, Draw bar, Milling chuck, 16mm Drill chuck, Drill sleeves
SKU TGMD400A-1
Brand ITM
Shipping Weight 390.0000kg
Type tools
Voltage 240
